Antaira SFP-10G-WB20-TAA

TX: 1330nm RX: 1270nm, 0~70C, with TAA Compliant
by ANTAIRA

11.32Gbps Data Links
Up to 20km Transmission on SMF
Single Mode Fiber Tx:1330 Rx:1270
2-Wire Interface with Integrated Digital Diagnostic Monitoring
EEPROM with Serial ID Functionality
Hot-Swappable SFP+ Design
Compliant with SFP+ Multi-Source Agreement
Single LC Connector
Single +3.3V Supplied Power
SFP-8472 Compliant
SFP-8431 Compliant
RoHS Compliant
Operating Temperature Range: -0° to 70° C
TAA Compliant

Description
Specification
Datasheet

SFP-10G-WB20-TAA

Antaira Technologies SFP-10G-WB20-TAA is a Hot Pluggable 3.3V Small-Form-Factor transceiver module. It is designed expressly for high-speed communication applications that require data transmission rates up to 11.32Gbps. It is compliant with SFF-8472 and SFP+ MSA, and the module data link is up to 20Km in 9/125um single mode fiber and is also TAA compliant

SFP-10G-WB20-TAA: 10G Fiber SFP+ Transceiver WDM-B, Single Mode 20Km/ LC/ TX: 1330nm RX: 1270nm, 0 to 70ºC (Cisco compatible)
