Powered by Annapurna Labs Alpine AL-314, quad-core 1.7 GHz processor, 2GB DDR3L RAM, one 1GbE LAN port and one 2.5GbE LAN port, the TS-231P3-2G-US features a 2.5GbE RJ45 port, providing up to 2.5 times the speed of regular Gigabit Ethernet and enabling smoother multimedia playback and everyday usage. The TS-231P3 ensures data security by supporting AES 256-bit encryption and various local/remote/cloud backup options – including snapshot protection that allows for files and data to be reverted to previously-recorded states if they are accidentally deleted, modified or affected by malware.
TS-231P3-2G-US
|
| CPU |
AnnapurnaLabs, an Amazon company Alpine AL314, 4-core, 1.7GHz |
| CPU Architecture |
32-bit ARM |
| Floating Point Unit |
|
| Encryption Engine |
|
| System Memory |
2GB SO-DIMM DDR3 |
| Maximum Memory |
8GB DDR3 |
| Memory Slot |
1 x SO-DIMM DDR3 |
| Flash Memory |
512 MB (Dual boot OS protection) |
| Drive Bay |
2 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| SSD Cache Acceleration Support |
|
| Gigabit Ethernet Port (RJ45) |
1 |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
1 |
| Jumbo Frame |
|
| USB 3.2 Gen 1 port |
3 |
| Form Factor |
Tower |
| LED Indicators |
Power, Status, LAN, USB, HDD1-2 |
| Buttons |
Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) |
169 × 102 × 219 mm |
| Weight (Net) |
1.46 kg |
| Weight (Gross) |
2.46 kg |
| Operating temperature |
0 - 40 °C (32°F - 104°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
60W Adapter, 100-240V |
| Power Consumption: HDD Sleep Mode |
8.46 W |
| Power Consumption: Operating Mode, Typical |
15.6 W Tested with drives fully populated. |
| Fan |
1 x70mm, 12VDC |
| Sound Level |
19.2 db(A) |
| System Warning |
Buzzer |
| Kensington Security Slot |
|
| Max. Number of Concurrent Connections (CIFS) |
400 |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications. Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
|
