REXP-1000-PRO - RAID Expansion Enclosure, Tower, 10-bay, Single Power Supply with 6G SAS Cable by QNAP

REXP-1000-PRO - RAID Expansion Enclosure, Tower, 10-bay, Single Power Supply with 6G SAS Cable
by QNAP

Write a review
  • Plug and use, seamless capacity expansion
  • Missing mode protection
  • High density, high efficiency and highly scalable
  • Powerful QTS Storage Manager
  • An excellent backup solution for the Turbo NAS
  • Flexible drive selection



Mfg SKU # : REXP-1000-PRO
Our Price : $1,199.00
In Stock :Call for Availability
Quantity :

The QNAP REXP-1000 Pro expansion enclosure is designed for expanding the storage space on the Turbo NAS and can support maximum 240TB raw capacity* by connecting multiple expansion enclosures via high-speed mini SAS cables. This is especially useful for large data applications, such as video surveillance, data archiving, and TV broadcast storage.

Plug and use, seamless capacity expansion

Simply connect a REXP-1000 Pro to a Turbo NAS* and power it on. The Turbo NAS will detect the hard drives in the REXP-1000 Pro as newly installed local drives. The Turbo NAS capacity can be expanded seamlessly by using the powerful QTS Storage Manager.

* Optional purchase of SAS expansion card and QTS 4.1.0 (or newer) are required for the Turbo NAS.

Missing mode protection

When disconnection of the expansion enclosures occurs, the Turbo NAS enters missing mode automatically and blocks I/O access to protect the stored data. The system can then recover from the missing mode to the normal state with data staying intact when the disconnection is resolved.

High density, high efficiency and highly scalable

The REXP-1000 Pro supports 10 hard drives and 60TB raw capacity, and has two SAS wide ports (IN port and OUT port) for host connectivity and daisy-chain respectively. Each SAS wide port combines four SAS channels (maximum 8 SAS channels supported per expansion enclosure). The solution delivers unprecedented performance of up to 24Gbps per host connection.

Powerful QTS Storage Manager

The QTS Storage Manager neatly presents tools and options for managing system storage with an intuitive graphical user interface, which simplifies the process of NAS capacity expansion and REXP-1000 Pro management. IT administrators can easily monitor the health status of REXP-1000 Pro and the disks within it. When cascading multiple expansion enclosures in a rack, the Locate Disk and Locate Enclosure functions assist IT administrators for quick maintenance.

An excellent backup solution for the Turbo NAS

In addition to expanding an existing volume, IT administrators can use the REXP-1000 Pro as a budget-friendly external storage to perform speedy and secure backup tasks for the Turbo NAS. The QNAP RTRR (Real-Time Remote Replication) or rsync service lets IT administrators back up the Turbo NAS data to the REXP-1000 Pro on a real time or scheduled basis.

Flexible drive selection

The REXP-1000 Pro offers high flexibility in hard drive selection. IT administrators can choose enterprise-level SAS HDDs with high performance and high reliability for mission critical applications, low-cost but high-capacity SATA HDDs for large data archiving, or high-speed and high stability SSDs for I/O intensive operations.

Host Interface Two SAS 6Gbps 4x wide port (IN port, OUT port)
Hard Drive 10 x 3.5-inch SAS/SATA 6Gb/s, SAS/SATA 3Gb/s hard drive or 2.5-inch SAS/SATA, SSD hard drive
  1. The standard system is shipped without hard drives.
  2. For the hard drive compatibility list, please visit compatibility.
LED Indicators Front panel: Status, fan error, system over heat, SAS link, SAS error, enclosure ID
Form Factor Tower
Dimensions 217.5(H) x 327(W) x 321.2(D) mm
8.54(H) x 12.87(W) x 12.65(D) inch
Weight Net weight (NAS only) : 9.24 kg/20.37 lb
Gross weight (with packing and accessories) : 13.78 kg/30.38 lb
Sound Level* Standby: 24.5 dB
Sound pressure (LpAm): 34.6 dB(A)
Power Consumption Sleep mode: 63.6W
In operation: 169.52W
(with 10 near line SAS hard drive installed)
Temperature 0-40˚C
Relative Humidity 5~95% RH non-condensing, wet bulb: 27˚C.
Power Supply ATX 350W, Input: 110-240 Vac~, 47-63Hz, 5A
COM Port Reserved for system maintenance
Fan 2 x 12 cm smart cooling fan

Front View:

1 LED Indicators: Status, Fan Error, System Over Heat, SAS Link, SAS Error
2 Enclosure ID
3 Hard Drive Tray
4 Tray Lock
5 Release Button
6 Hard Drive LEDs

Rear View:

1 Power Connector
2 Power Switch
3 K-Lock Security Slot
4 IN Port
5 OUT Port
6 COM Port (Reserved)
7 System Cooling Fans

* Testing Environment:
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS
