Advantech WSKIT3BC-CBM-V - Wzzard Conditon Based Monitoring Kit, Cell GW, with Vibration Sensor
by Advantech
|
|
|
|
Wzzard™ Technologies
- Wzzard Intelligent Edge Nodes, which connect to industry-standard sensors
- SmartMesh IP wireless sensing technology which enables auto-forming, self-healing, self-sustaining networks that are also highly scalable
- MQTT - a simple messaging transport protocol for M2M/IoT applications over wireless networks
- Spectre Network Gateway which serves as the gateway, connecting equipment and devices to the Internet or Intranet over either wired Ethernet or wireless cellular connections
Applications
- Energy Consumption
- Condition-based Monitoring
- Water Level, including irrigation systems, tank level, and flood control
- Structural Systems Monitoring
- Perimeter Access Control
- Agricultural, including silo monitoring
- Smart Parking Systems
- Temperature and Environmental Monitoring
|
|
|
What is Wzzard?
The Wzzard platform uses wireless Wzzard Intelligent Edge Nodes and the Spectre Network Gateway work together to create a wireless sensor network.
- The wireless Wzzard Intelligent Edge Nodes connect to your sensors and send the data to the gateway via wireless mesh networks.
- The edge nodes convert your sensor data to the publish/subscribe MQTT format, making it available to multiple applications on your network or in the cloud.
- The nodes can be configured to report only the data that has exceeded preconfigured thresholds, greatly reducing network traffic and further extending battery life.
- The Spectre Network Gateway aggregates the data from the Wzzard mesh networks and securely sends it to the included dashboard application featuring sensor data visualization, history and alarm capability through email or SMS.
Included Hardware
WSKIT3BE-CBM, WSKIT3BC-CBM
- (3) Wzzard™ WSD2CA3 Industrial (-40c to +85c). WSD2CJA (2 Thermocouple in, 2 AI). Each node supports up to 3 attached sensors.
- (1) ERT-351 Ethernet or (1) RT3G-350 Cellular network gateway with Dust board (One gateway supports up to 32 wireless sensor nodes and up to 96 attached sensors).
- (6) J Type Thermocouples.
- (3) 250A Clamp On Current Sensors.
WSKIT3BE-CBM-V, WSKIT3BC-CBM-V (In addition to the WSKIT3BE-CBM parts listed above)
- (3) Vibration 4-20 ma sensors
- (3) Vibration cables
- (3) DIN rail mount power supply 24VDC
- (3) RES 250 OHM 1/2W .1% AXIAL * Vibration sensors require external power
Included Software
- One copy Window PC-based SmartWorx Energy Monitoring Platform software.
- Real time data display
- Historian Trending.
- User programmable thresholds limits.
- Visual and email/SMS alerts.
- 3rd party SaaS platform support.
|
|
|
|
