| Physical Ports |
|
10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX |
4 |
| Technology |
|
| Ethernet Standards |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow control
IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.) |
| MAC Table |
8192 MAC addressessses |
| Processing |
Store-and-Forward |
| LED Indicators |
|
Power indicator |
Green : Power LED x 2 |
| Fault Indicator |
Amber : Indicates PWR1 or PWR2 failure occurred |
10/100/1000Base-T(X) RJ45 port indicator and PoE indicator (P1 ~ P4) |
Green for port Link/Act.
Green for PoE power injected |
10/100/1000Base-T(X) RJ45 port indicator (P5) |
Green for port Link/Act.
Amber for 100Mbps indicator |
DIP-Switch |
|
DIP-Switch 1 |
Power-1 failed warning : (ON) enable, (OFF) disable |
DIP-Switch 2 |
Power-2 failed warning : (ON) enable, (OFF) disable |
| Fault contact |
|
| Relay |
Relay output to carry capacity of 1A at 24VDC |
| Power |
|
| Redundant Input Power |
Dual DC inputs. 50~57VDC on 6-pin terminal block. |
| Power consumption (Typ.) |
6.1 Watts |
Overload current protection |
Present |
Reverse polarity protection |
Not Present |
Physical Characteristics |
|
| Enclosure |
IP-30 |
| Dimensions (W x D x H) |
26.1 (W) x 94.9 (D) x 144.3(H) mm (1.03 x 3.74 x 5.68 inches) |
| Weight (g) |
407 g |
| Environmental |
|
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Operating Temperature |
-40 to 70°C (-40 to 158°F) |
| Operating Humidity |
5% to 95% Non-condensing |
| Regulatory Approvals |
|
| EMI |
FCC Part 15, CISPR (EN55022) class A |
| EMS |
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8,EN61000-4-11 |
| Shock |
IEC60068-2-27 |
| Free Fall |
IEC60068-2-32 |
| Vibration |
IEC60068-2-6 |
| Safety |
EN60950-1 |
