Moxa PM-7200-4GSFP-PHR-PTP - Gigabit Ethernet module with 4 100/1000Base SFP slots, PRP/HSR protocol support
by MOXA
|
|
|
|
- IEEE 1588v2 PTP with hardware time stamping for precise time synchronization of networks
- IEC 61850-3 and IEEE 1613 (power substations) compliant
- IEC 62439-3 Clause 4 (PRP) and Clause 5 (HSR) compliant*
- Isolated redundant power supplies with universal 24 VDC, or 48 VDC, or 110/220 VDC/VAC power supply range
- -40 to 85°C operating temperature range
- Built-in MMS server based on IEC 61850-90-4 switch data modeling for Power SCADA
*Only available with PM-7200-4GTX-PHR-PTP and PM-7200-4GSFP-PHR-PTP modules
|
|
|
The PowerTrans PT-7728-PTP switches are designed to meet the demands of power substation automation systems (IEC 61850-3, IEEE 1613). The PT-7728-PTP’s redundant ring, and dual isolated redundant power supplies increase the reliability of your communications and save on cabling/wiring costs. Moxa’s PT-7728-PTP IEC 61850-3 Fast Ethernet switches support the latest version of IEEE 1588 technology (IEEE 1588v2 PTP) to fulfill precision time synchronization requirements for protection and control applications. These Ethernet switches guarantee time-stamping accuracy within 1 μs for the IEC 61850 process layer. They can be configured for 1588 v2 Master, Boundary Clock, and Transparent Clock functionality. The modular design of the PT-7728-PTP also makes network planning easy, and allows greater flexibility by letting you install up to 14 IEEE 1588 Fast Ethernet ports or up to 24 non-IEEE 1588 Ethernet ports and 4 Gigabit ports. Along with a choice of either front or rear wiring, these features together make the PT-7728-PTP suitable for a variety of industrial applications.
| • Technology |
| Standards |
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
IEEE 802.3x for Flow Control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.1X for Authentication
IEEE 802.3ad for Port Trunk with LACP |
| • Software Features |
| Management |
IPv4/IPv6, SNMPv1/v2c/v3, DHCP Server/Client, DHCP Option 66/67/82, BootP, TFTP, SNTP, SMTP, RARP, RMON, HTTP, HTTPS, Telnet, SNMP Inform, LLDP, Flow Control, Back Pressure Flow Control, Port Mirror, Fiber Check, Syslog |
| Filter |
IGMPv1/v2, GMRP, GVRP, 802.1Q, Q-in-Q VLAN |
| Redundancy Protocols |
STP/RSTP, MSTP, Turbo Ring v1/v2, Turbo Chain, Link Aggregation, PRP, HSR |
| Security |
RADIUS, TACACS+, SSL, SSH, Port Lock, Broadcast Storm Protection |
| Time Management |
SNTP, NTP Server/Client, IEEE 1588v2 PTP (hardware-based) |
| Industrial Protocols |
EtherNet/IP, Modbus/TCP |
| MIB |
MIB-II, Ethernet-like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9, IEC 62439-3 MIB |
| Power Substation |
MMS, IEC 61850 QoS |
| • Switch Properties |
| Priority Queues |
4 |
| Max. Number of VLANs |
64 |
| VLAN ID Range |
VID 1 to 4094 |
| IGMP Groups |
256 |
| • Interface |
| IEEE 1588 PTP |
Up to 12 x 10/100BaseT(X), 12 x 100BaseFX (multi-mode, SC connector), or 14 x 100BaseFX (multi-mode, ST connector) and 4 x 10/100/1000BaseT(X) or 4 x 100/1000BaseSFP IEEE 1588 ports with hardware time stamping |
| Fast Ethernet |
• Slots 1, 2, and 3 for combinations of 2, 4, 6, or 8-port PM-7200 Fast Ethernet modules with 10/100BaseT(X) (TP/M12 interface), 100BaseFX (SC/ST/MTRJ connector), or 100BaseSFP
• Slot 4 for BNC port and 100BaseFX (ST connector) |
| Gigabit Ethernet |
Slot 4 for 2 or 4-port PM-7200 Gigabit Ethernet combo module or 4-port PM-7200 Gigabit Ethernet PRP/HSR module, 10/100/1000BaseT(X) or 1000BaseSFP |
| Console Port |
RS-232 (RJ45) |
| Alarm Contact |
1 relay output with current carrying capacity of 3 A @ 30 VDC or 3 A @ 240 VAC |
| • Power Requirements |
| Input Voltage |
• 24 VDC
• 48 VDC
• 110/220 VDC/VAC |
| Operating Voltage |
• 18 to 36 V (24 VDC)
• 36 to 72 V (48 VDC)
• 88 to 300 VDC, 85 to 264 VAC (110/220 VDC/VAC) |
| Input Current |
(all ports are equipped with fiber)• Max. 2.38 A @ 24 VDC
• Max. 1.12 A @ 48 VDC
• Max. 0.59/0.30 A @ 110/220 VDC
• Max. 0.49/0.26 A @ 110/220 VAC |
| Overload Current Protection |
Present |
| Connection |
10-pin terminal block |
| Reverse Polarity Protection |
Present |
| • Physical Characteristics |
| Housing |
Aluminum alloy |
| IP Rating |
IP30 protection |
| Dimensions |
440 x 44 x 325 mm (17.32 x 1.73 x 12.80 in) |
| Weight |
5900 g (13.11 lb) |
| Installation |
19-inch rack mounting |
| • Environmental Limits |
| Operating Temperature |
-40 to 85°C (-40 to 185°F), cold start requires min. of 100 VAC at -40°C |
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity |
5 to 95% (non-condensing) |
| • Standards and Certifications |
| Safety |
UL 60950-1, CSA C22.2 No. 60950-1, EN 60950-1 |
| EMI |
FCC Part 15 Subpart B Class A, EN 55032 Class A |
| EMS |
IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 35 V/m
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV
IEC 61000-4-5 Surge: Power: 4 kV; Signal: 4 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
IEC 61000-4-11 |
| Electrical Substation |
IEC 61850-3, IEEE 1613 |
| • MTBF (mean time between failures) |
| Time |
340,365 hrs |
| Standard |
Telcordia SR332 |
|
|
|
|
