Advantech AMAX-5056-A
8-ch Sink-type Digital Output EtherCAT Slice IO Module
- Channels: 8 (Sink Type)
- Voltage Rating: 10~30VDC
- Rated Current Output: 0.3A per channel at signal "1"
- Leakage Current: 25 μA per channel at signal "0"
- Output Delay: From logic level 0 to 1: 10μs; From logic level 1 to 0: 100μs
