Advantech ESRP-PCS-ADAM6717 - 8AI/5DI/4DO Intelligent I/O Gateway with WISE-EdgeLink
by Advantech

ESRP-PCS-ADAM6717 intelligent I/O gateways have Linux OS installed and perform multiple tasks at the edge. ADAM-6700 with built-in WISE-EdgeLink supporting 200+ drivers and transmitting data from the edge to cloud, is designed as an integrated solution for factory management and energy monitoring.

Analog Input
Channels	8
Input Range	+0.15 V +0.5 V, 1 V, +5 V, +10 V, +20 mA, 0~20 mA, 4~20 mA, 0~0.15V, 0~0.5 V, 0~1 V, 0~5 V, 0~10 V
Input Type	V, mV, mA
Resolution(Bits)	16-bit
Sampling Rates(S/s)	100 S/s (sum)
Environment
Isolation Voltage	2,500 VDC
Operating Temperature	-40~70 °C (-40~158 °F)
Ethernet
No. of Ports	2
Speed	10/100 Mbps
General
Connectors	1 X 9-pin plug-in screw terminal, 2 X 15-pin plug-in screw terminal
Protocol	OPC-UA Client & Server, IEC-60870-5-104 Master & Slave, IEC-60870-5-101 Slave, Modbus RTU/TCP Master & Slave, BACNet/IP Server
Hardware
I/O	2 X RS-485, 1 X Micro USB, 1 X USB 2.0
os Support	Linux
Storage	1 X micro SD Slot
Isolated Digital Input
Channels	5
Input Voltage	Dry Contact Logic level 1: close to GND Logic level 0: open Wet Contact Logic level 1: 10~30 VDC Logic level 0: 0~3 VDC
Isolated Digital Output
Channels	4
Output Type	Sink
Output Voltage	0~30 VDC
Sink Current	100 mA max./channel
Power Requirements
Input Voltage	10~30 VDC
