Moxa M-1450 - I/O Module, 4DI, 110VAC, RTB
by MOXA
|
|
|
|
I/O Module, 4DI, 110VAC, RTB
|
|
|
I/O Module, 4DI, 110VAC, RTB
| Digital Inputs |
4 channels |
| On-state Voltage |
120 VAC nominal, min. 85 VAC to max. 132 VAC |
| Min. Off-state Voltage |
Max. 45 VAC |
| On-state Current |
Max. 8 mA/point @ 132 VAC |
| Input Impedance |
Typ. 11K ohms |
| Common Type |
4 channels for 2 COMs (single common) |
| Power Consumption |
35 mA @ 5 VDC |
|
|
