Moxa M-2601 - I/O Module, 16DO, Source, 24VDC, 0.3A, 20pin
by MOXA
|
|
|
|
I/O Module, 16DO, Source, 24VDC, 0.3A, 20pin
|
|
|
I/O Module, 16DO, Source, 24VDC, 0.3A, 20pin
| Digital Outputs |
16 channels, source type |
| Output Voltage Range |
24 VDC nominal, min. 11 VDC to max. 28.8 VDC |
| On-state Voltage Drop |
Max. 0.3 VDC @ 25°C |
| On-state Current |
Min. 1 mA per channel |
| Off Leakage Current |
Max. 50 µA |
| Current Rating |
• 0.5 A per channel
• 4 A per common |
| Common Type |
16 channels for 2 COMs (single common) |
| Power Consumption |
80 mA @ 5 VDC |
|
|
|
|
|
|
