I-7033 is intelligently designed to provide signal conditioning system monitoring and safe value settings. I-7033 is a cost-effective solution for a wide range of valuable industrial control signals and systems. The DCON utility can help users to configure and test I-7033 RTD Input modules. Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems. Users may mount the modules on a DIN rail, panel or wall. Modules have a screw-terminal block to connect to the signals. I-7033 comes with FREE EZ Data Logger Software.
- Photo-isolation: 3750 Vrms
- Channels: 3
- Input Type: Pt , Ni
- Sampling rate:
- 15/12.5 samples/second
- while filter at 60/50Hz
- Bandwidth: 15.7 Hz
- Wire connection: 2/3/4 wire
- Accuracy: ± 0.1%
- Zero drift : ± 0.5uV/°C
- Span drift: ±25uV/°C
- CMR @ 50/60 Hz: 150 dB min
- NMR @ 50/60 Hz: 100 dB min
Display LED
- 4 1/2 digits (for M-7033D only)
|
|
Pt100 α=0.00385
Pt100 α=0.003916
Ni 120
Pt1000 α=0.00385
| RTD temperature range |
| Pt100 |
-100°C |
to |
+100°C |
α=0.00385 |
| Pt100 |
0°C |
to |
+100°C |
α=0.00385 |
| Pt100 |
0°C |
to |
+200°C |
α=0.00385 |
| Pt100 |
0°C |
to |
+600°C |
α=0.00385 |
| Pt100 |
-100°C |
to |
+100°C |
α=0.003916 |
| Pt100 |
0°C |
to |
+100°C |
α=0.003916 |
| Pt100 |
0°C |
to |
+200°C |
α=0.003916 |
| Pt100 |
0°C |
to |
+600°C |
α=0.003916 |
| Ni120 |
-80°C |
to |
+100°C |
|
| Ni120 |
0°C |
to |
+100°C |
|
| Pt 1000 |
-200°C |
to |
-600°C |
α=0.00385 |
|
Power Supply
- Input Voltage Range: +10 to +30 Vdc
- Consumption: 1.0W for M-7033 1.6W for M-7033D
Mount
|
