Wireless Communication
IEEE Standard IEEE 802.15.4
Modulation Type DSSS (OQPSK)
Frequency Band ISM 2.4 GHz (2.4 GHz ~ 2.4835 GHz)
Channels 11 - 26
RF Data Rate 250 Kbps
Transmit Power Typ. 19 ± 1 dBm
Receiver Sensitivity -97 dBm
Topology Star / Tree / Mesh
Outdoor Range 1000 m with line of sight (with 2 dBi Antenna)
Network Capacity 32 nodes (Routers & End Devices)* *Based on user's configuration
Range Extenders Maximum 5 Hops
Function Coordinator General
Connectors 1 x plug-in terminal block (#14 ~ 22 AWG) 1 x USB-type A connector (type A to B cable provided)
Protocol Modbus RTU
Power Input Unregulated 10 ~ 30 VDC
Battery Input 2 x AA Alkaline
Power Consumption 0.8 W @ 24 VDC 0.5 W @ 5 VDC (USB) 0.3 W @ 3 VDC (Battery AA * 2)
