Physical Ports |
|
100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX |
1 |
100/1000Base-X SFP Port |
1 |
Technology |
|
Ethernet Standards |
IEEE 802.3u for 100Base-TX and 100Base-FX
IEEE 802.3z for 1000Base-X
IEEE 802.3ab for 1000Base-T |
Processing |
Store-and-Forward |
DIP-Switch |
DIP-Switch 1 (ON) and 2 (ON) : SFP speed setting to 100Mbps
DIP-Switch 1 (OFF) and 2 (OFF) : SFP speed setting to 1000Mbps |
LED Indicators |
|
Power Indicator |
Green : Power LED x 2 |
100/1000Base-T(X) RJ45 port Indicator |
LED for Link/Act and Speed indicator ~
Green on only : 1000Mbps Link/Act
Green and Amber on : 100Mbps Link/Act
Note : If Amber on only : 10Mbps (This is not avail mode) |
100/1000Base-X SFP port Indicator |
Green for port Link/Act. |
Power |
|
Redundant Input Power |
Dual 12 ~ 48VDC power inputs at 4-pin terminal block |
Power Consumption (Typ.) |
3.6 Watts |
Overload Current Protection |
Present |
Reverse Polarity Protection |
Present |
Physical Characteristics |
|
Enclosure |
IP-30 |
Dimensions (W x D x H) |
26.1(W) x 70(D) x 95(H) mm (1.03 x 2.76 x 3.74 inch.) |
Weight (g) |
190g |
Environmental |
|
Storage Temperature |
-40 to 85°C (-40 to 185°F) |
Operating Temperature |
-40 to 70°C (-40 to 158°F) |
Operating Humidity |
5% to 95% Non-condensing |
Regulatory Approvals |
|
EMI |
FCC Part 15, CISPR (EN55022) class A, EN50155 (EN50121-3-2, EN55011,
EN50121-4) |
EMS |
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5
(Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11 |
Shock |
IEC60068-2-27 , EN61373 |
Free Fall |
IEC60068-2-32 |
Vibration |
IEC60068-2-6 , EN61373 |
Safety |
EN60950-1 |
Warranty |
5 years |
