PTC-101-S-LC-LV - Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with LC connector, dual redundant power in by MOXA
|
|
|
- 10/100BaseT(X) auto-negotiation and auto-MDI/MDI-X
- Link Fault Pass-Through (LFPT)
- Power failure alarm by relay output (LV model only)
- -40 to 85°C operating temperature range
- Redundant dual DC power inputs (LV model only)
- Integrated high-reliability power supply eliminates the need for external power transformer
|
|
|
The PTC-101-S-LC-LV, Ethernet-to-fiber media converters convert from 10/100BaseT(X) to 100BaseFX. Models are available with either SC, ST, or LC connectors. The PTC-101 converters eliminate the need for additional wiring, and support IEEE 802.3 and IEEE 802.3u/x protocols with 10/100M, full/half-duplex, and MDI/MDI-X auto-sensing to provide a total solution for your industrial Ethernet networks. The PTC-101 is compliant with mandatory sections of IEC 61850-3, covering operating temperature, power input voltage, surge, ESD, and vibration, as well as conformal coating and power insulation, making the media converters suitable for a variety of industrial applications.
Ethernet Interface
Power Parameters
-
Input Voltage
LV-DC models: 20 to 72 VDC
HV-AC models: 100 to 240 VAC
HV-DC models: 88 to 300 VDC
-
Input Current
LV-DC models: 150 mA @ 20 to 72 VDC
HV-AC models: 200 to 350 mA @ 100 to 240 VAC
HV-DC models: 47 mA @ 88 VDC
-
Overload Current Protection
Supported
-
Power Consumption
LV-DC models: 150 mA @ 20 to 72 VDC
HV-AC models: 200 to 350 mA @ 100 to 240 VAC
HV-DC models: 47 mA @ 88 VDC
Physical Characteristics
Environmental Limits
-
Operating Temperature
-40 to 85°C (-40 to 185°F)
-
Storage Temperature (package included)
-40 to 85°C (-40 to 185°F)
-
Ambient Relative Humidity
5 to 95% (non-condensing)
Standards and Certifications
-
EMC
EN 55032/24
-
EMI
CISPR 32, FCC Part 15B Class A
-
EMS
IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV
IEC 61000-4-5 Surge: Power: 4 kV; Signal: 4 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m
IEC 61000-4-8 PFMF
IEC 61000-4-11
-
Environmental Testing
IEC 60068-2-1
IEC 60068-2-14
IEC 60068-2-2
IEC 60068-2-3
-
Safety
EN 60950-1, UL 60950-1
-
Vibration
IEC 60068-2-6
-
Power Substation
IEC 61850-3
MTBF
-
Time
1,211,613 hrs
-
Standards
MIL-HDBK-217F
|
|
