Moxa NPort W2150A-W4-T-US - 1-port RS-232/422/485 wireless device server with 802.11a/b/g/n WLAN US band, 12 to 48 VDC
by MOXA
|
|
|
|
NPort W2150A-W4-T-US_SUMMARY.html
- Links serial and Ethernet devices to an IEEE 802.11a-b-g-n network
- Web-based configuration using built-in Ethernet or WLAN
- Secure Boot that only allows Moxa-authorized firmware to run on devices
- Remote configuration with HTTPS, SSH
- Secure data access with WEP, WPA, WPA2
- Fast roaming for quick automatic switching between access points
- Offline port buffering and serial data log
- Enhanced surge protection for serial, LAN, and power
- Dual power inputs (1 screw-type power jack, 1 terminal block)
|
|
|
NPort W2150A-W4-T-US_DESCRIPTION.html
The NPort®W2150A-W4 and W2250A-W4 are the ideal choice
for connecting your serial and Ethernet devices, such as PLCs, meters,
and sensors, to a wireless LAN. Your communications software will
be able to access the serial devices from anywhere over a wireless
LAN. Moreover, the wireless device servers require fewer cables and
are ideal for applications that involve difficult wiring situations.
In Infrastructure Mode, the NPort®W2150A-W4 and NPort®W2250A-W4
can connect to Wi-Fi networks at offices and factories to allow users
to move, or roam, between several APs (access points), and offer an
excellent solution for devices that are frequently moved from place
to place.
NPort W2150A-W4-T-US.html
Ethernet Interface
-
10/100BaseT(X) Ports (RJ45 connector)
-
Magnetic Isolation Protection
-
Standards
- IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
Ethernet Software Features
-
Configuration Options
- Web Console (HTTP/HTTPS)
Windows Utility
-
Management
- DHCP Option 82
HTTP
IPv4
SMTP
SNMPv1/v2c/v3
Syslog
Telnet
Web
Console
-
Windows Real COM Drivers
- Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10/11 (x86/ x64), Windows 2008
R2/2012/2012 R2/2016/2019 (x64), Windows Server 2022, Windows XP Embedded
-
Linux Real TTY Drivers
- Kernel versions: 2.4.x, 2.6.x, 3.x, 4.x, and 5.x
-
Fixed TTY Drivers
- SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX
11i, Mac OS X
-
Android API
-
MIB
- Device Settings MIB
RFC1213, RFC1317
-
Security
- HTTPS/SSL
User Authentication Management: local database, RADIUS
Secure Protocols:
HTTPS (TLSv1.2), SSH, SNMPv3
Cryptography: HMAC, SHA-1, SHA-256, SHA-384, RSA-1024,
AES-128, AES-256
-
Time Management
WLAN Interface
-
WLAN Standards
-
Receiver Sensitivity for 802.11a (measured at 5.680 GHz)
- Typ. -91 @ 6 Mbps
Typ. -74 @ 54 Mbps
-
Receiver Sensitivity for 802.11b (measured at 2.437 GHz)
- Typ. -92 dBm @ 1 Mbps
Typ. -84 dBm @ 11 Mbps
-
Receiver Sensitivity for 802.11g (measured at 2.437 GHz)
- Typ. -91 dBm @ 6 Mbps
Typ. -73 dBm @ 54 Mbps
-
Receiver Sensitivity for 802.11n (2.4 GHz; measured at 2.437 GHz)
- Typ. -89 dBm @ 6.5 Mbps (20 MHz)
Typ. -71 dBm @ 72.2 Mbps (20 MHz)
-
Receiver Sensitivity for 802.11n (5 GHz; measured at 5.680 GHz)
- Typ. -89 dBm @ 6.5 Mbps (20 MHz)
Typ. -71 dBm @ 72.2 Mbps (20 MHz)
Typ. -85 dBm
@ 13.5 Mbps (40 MHz)
Typ. -67 dBm @ 150 Mbps (40 MHz)
-
Modulation Type
-
Transmission Distance
- Up to 100 meters (in open areas)
-
Transmission Rate
- 802.11a/g: 54 Mbps
802.11b: 11 Mbps
802.11n: 6.5 to 150 Mbps
-
Transmitter Power for 802.11b
- 16± 1.5 dBm @ 1 Mbps
16± 1.5 dBm @ 11 Mbps
-
Transmitter Power for 802.11g
- 16± 1.5 dBm @ 6 Mbps
14 ± 1.5 dBm @ 54 Mbps
-
Transmitter Power for 802.11a
- 15± 1.5 dBm @ 6 Mbps
14 ± 1.5 dBm @ 54 Mbps
-
Transmitter Power for 802.11n (2.4 GHz)
- 16 dBm @ 1.5 Mbps (6.5 MHz)
12 dBm @ 1.5 Mbps (72.2 MHz)
-
Transmitter Power for 802.11n (5 GHz)
- 15 dBm @ 1.5 Mbps (6.5 MHz)
12 dBm @ 1.5 Mbps (150 MHz)
-
Frequency Band for CN (20 MHz operating channels)
- 2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320
GHz (4 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
5.745 to 5.825 GHz (5 channels)
-
Frequency Band for EU (20 MHz operating channels)
- 2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320
GHz (4 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
5.500 to 5.700 GHz (11 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
-
Frequency Band for JP (20 MHz operating channels)
- 2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320
GHz (4 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
5.500 to 5.700 GHz (11 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
-
Frequency Band for US (20 MHz operating channels)
- 2.412 to 2.462 GHz (11 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320
GHz (4 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
5.500 to 5.700 GHz (11 channels) \t\t\tDFS (Dynamic Frequency Selection) channel support:
In AP mode, when a radar signal is detected, the device will automatically
switch to another channel. However, according to regulations, after switching
channels, a 60-second availability check period is required before starting the
service.\t
5.745 to 5.825 GHz (5 channels)
-
Wireless Security
- WEP encryption (64-bit and 128-bit)
WPA/WPA2-Enterprise (IEEE 802.1X/RADIUS, TKIP,
AES)
WPA/WPA2-Personal
-
WLAN Modes
Antenna Characteristics
Security Functions
-
Authentication
-
Encryption
- AES-128
AES-256
HMAC
RSA-1024
SHA-1
SHA-256
SHA-384
-
Security Protocols
- SNMPv3
SSHv2
HTTPS (TLS 1.2)
-
Wireless Security
- WEP
WPA/WPA2-Enterprise
WPA/WPA2-Personal
-
Hardware-based Security
Serial Interface
-
Connector
-
No. of Ports
-
Serial Standards
-
Operation Modes
- Real COM mode
TCP Server mode
TCP Client mode
UDP mode
RFC2217 mode
Pair Connection mode
Ethernet Modem mode
Disabled
-
Baudrate
-
Data Bits
-
Stop Bits
-
Parity
- None, Even, Odd, Space, Mark
-
Flow Control
-
RS-485 Data Direction Control
- ADDC (automatic data direction control)
-
Pull High/Low Resistor for RS-485
- 1 kilo-ohm, 150 kilo-ohms
-
Terminator for RS-485
-
Surge
Physical Characteristics
-
Housing
-
Installation
- Desktop
DIN-rail mounting (with optional kit)
Wall mounting
-
Dimensions (with ears, without antenna)
- 100 x 111 x 26 mm (3.94 x 4.37 x 1.02 in)
-
Dimensions (without ears or antenna)
- 77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in)
-
Weight
-
Antenna Length
Environmental Limits
-
Operating Temperature
- Standard Models: 0 to 55C (32 to 131F)
Wide Temp. Models: -40 to
75C (-40 to 167F)
-
Storage Temperature (package included)
-
Ambient Relative Humidity
- 5 to 95% (non-condensing)
Power Parameters
-
Input Current
-
Input Voltage
Standards and Certifications
-
EMC
-
EMI
- CISPR 32, FCC Part 15B Class A
-
EMS
- IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC
61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT:
Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2
kV; Signal: 1 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3
V/m; Signal: 3 V/m
IEC 61000-4-8 PFMF
IEC 61000-4-11
-
Radio Frequency
- CE (ETSI EN 301 893, ETSI EN 300 328, ETSI EN 301489-1/-17),
MIC, KC, RCM, WPC
-
Safety
Reliability
-
Alert Tools
-
Automatic Reboot Trigger
MTBF
|
|
|
|
