Physical Ports |
|
10/100 Base-T(X) Ports in RJ45 Auto MDI/MDIX |
1 |
USB Host port |
1x USB 2.0 Host port |
Technology |
|
List |
USB modems and ISDN adapters which support the Communication Device Class Abstract Control Model interface
List of tested device :
Hummingbird huc56s (Conexant)
Huawei E220/E230
Simense HSDPA-180C
Prolific 2303 + serial modem
Quanta MUQ101
Sony Ericsson MD400/MD400g
Sierra C885 |
LED Indicators |
|
Power Indicator |
Green On : Power is on |
Ready Indicator |
Green : Transmission status |
Fault Indicator |
Amber On : WAN connection link down |
USB Indicator |
Green On : USB modem is present |
10/100 Base-T(X) RJ45 Port Indicator |
Green Blinking : Ethernet port is transmitting data |
Fault contact |
|
Relay |
Relay output to carry capacity of 1A at 24VDC |
Power |
|
Redundant Input power |
12~ 48 VDC voltage power input at 4-pin terminal block |
Power consumption (Typ.) |
3.3W |
Overload current protection |
Present |
Reverse polarity protection |
Present |
Physical Characteristic |
|
Enclosure |
IP-30 |
Dimension (W x D x H) |
26.1(W)x70(D)x95(H) mm (1.03x2.76x3.74 inches) |
Weight (g) |
190 g |
Environmental |
|
Storage Temperature |
-40 to 85°C (-40 to 185°F) |
Operating Temperature |
-20 to 70°C (-4 to 158°F) |
Operating Humidity |
5% to 95% Non-condensing |
Regulatory approvals |
|
EMI |
FCC Part 15, CISPR (EN55022) class A |
EMS |
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11 |
Shock |
IEC60068-2-27 |
Free Fall |
IEC60068-2-32 |
Vibration |
IEC60068-2-6 |
Safety |
EN60950-1 |
