Input Voltage |
11V to 60VDC, Dual Inputs |
Input Current |
9.86A @11VDC IN (Full Load)
4.446 @ 24VDC IN (Full Load)
2.26A @ 48VDC IN (Full Load) |
Output Voltage |
IEEE802.3bt 56VDC ; Load Reg = 5%, Line Reg = 1% |
Output Current / Max Watts |
1.67A / 95W with 34VDC to 60VDC Input
1.43A / 80W with 11VDC to 33VDC Input |
Ripple & Noise |
1% |
Efficiency |
>90% at 34-60VDC Input ; >86% at 11-33VDC Input |
Protections |
Short Circuit, Reverse Voltage |
Over Current Protection |
802.3bt Class 8 (96.6W) |
Low Voltage Detect (LVD) |
Device with stop drawing all current when input voltage drops below 8~9VDC |
Misc Protections |
Short Circuit, Reverse Voltage |
Data PassThrough |
10/100/1000/5000Mbps ; Gigabit |
Data Protection |
Pin to Pin (1-2, 3-6, 4-5, 7-8)
Clamp Voltage: 3.3V
ESD, IEC61000-4-2: +/- 30KV contact and air
EFT, IEC61000-4-4: 40A (5/50us)
Lightning, IEC61000-4-5: 15A (8/20us) |
MTBF |
114,311 hrs |
Connections |
Removable Wire Terminal |
Wire Size |
12AWG Max |
LED Function |
Green Power LED = Input Power is OK
RJ45 Green LED = 802.3bt negotiation and output is OK |
Mounting |
DIN Rail |
Operating Temperature |
-40C to +70C (-40F to 158F) |
Humidity (RH) |
5% - 90% Non-Condensing |
Dimensions (LxWxD) |
125 x 66 x 102 mm (4.9” x 2.6” x 4”) |
Weight |
0.6kg (1.30lb) |
