TP-VR-1212 - *Discontinued* - Voltage Regulator 12-15VDC input, 12V @ 1.5A regulated output. 18W. 12' 18AWG lead wires by Tycon Systems

TP-VR-1212 - *Discontinued* - Voltage Regulator 12-15VDC input, 12V @ 1.5A regulated output. 18W. 12" 18AWG lead wires
by Tycon Systems
Write a review Write a review
  • Compact Size , Sealed Design
  • High Output , Short Circuit Protected
  • 12" 18AWG Lead Wires



Mfg SKU # : TP-VR-1212
Our Price : $21.95
Stock : Call for Availability
Quantity :

The TP-VR-1212 is an 18W voltage converter/regulator which accepts an input of 12VDC to 15VDC and provides a regulated output of 12VDC @ 1.5A 18W. These units are perfect for providing stable regulated 12VDC voltage from 12VDC battery banks.

DC Input Voltage Range 12V to 15VDC
DC Voltage Output 10.6V to 12.5V @ 1.5A
Maximum Power Dissipation 18W
Efficiency 80%
Load / Line Regulation 5% / 1%
Ripple / Noise 2% / 5%
Wire Gauge 18AWG
Lead Wire Length 12"
Operating Temperature 5°F to 104°F ( - 15°C to +40°C)
Operating Humidity 0 to 99% RH
Size 2.75 x 1.25 x 1” (70x32x25mm)
Weight 1.5oz (43g)
Warranty 2 Years
