Antenna Characteristics
Frequency: 2.4 to 2.5, 4.9 to 5.825 GHz
Anntenna Type: Omni-directional
Typical Antenna Gain: 3.5/6 dBi
Connector: N-type (male)
Impedance: 50 ohms
Polarization: Linear, vertical or horizontal
V.S.W.R.: 2:1 max.
Power Handling: 1 W max.
Physical Characteristics
Weight: 68.96 g
Dimensions: Diameter: 22 mm Length: 215 mm
IP Rating: IP67
Radome Color: White
Radome Material: PC-9330
Environmental Limits
Operating Temperature: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 75°C (-40 to 167°F)
Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)
