QNAP TS-463XU-4G-US - *Discontinued* - 1U 4-Bay AMD 64bit x86-based NAS and iSCSI/ IP-SAN, Quad Core 2.0GHz, 4GB RAM, 4 x 1GbE,
by QNAP
|
|
|
|
- Built-in single-port 10GbE 10GBASE-T NIC to accelerate virtualization and high-resolution video editing and sharing.
- Qtier™ auto-tiering technology and SSD caching enable constant storage optimization.
- Snapshots fully record system status and data, and assist in quick data recovery and mitigating the threat of ransomware attacks.
- Host containerized applications and virtual machines with various operating systems.
- Secure private cloud supporting centralized storage, backup, sharing, and disaster recovery.
- NAS and iSCSI-SAN (IP-SAN) unified storage solution with scalable design.
| Mfg SKU # : | TS-463XU-4G-US |
|
|
|
The cost-efficient 10GbE-ready TS-463XU-4G-US is powered by a high-performance AMD G-Series quad-core processor. Featuring native 10GbE connectivity that delivers high performance with persistent throughput, along with storage scalability, the TS-463XU is perfect for businesses that demand higher bandwidth for data centers and virtualization.
|
| CPU |
AMD G-Series GX-420MC quad-core 2.0 GHz processor |
| CPU Architecture |
64-bit x86 |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| System Memory |
4 GB SO-DIMM DDR3L (1 x 4 GB) |
| Maximum Memory |
16 GB (2 x 8 GB) |
| Memory Slot |
2 x SO-DIMM DDR3L For dual-DIMM configuration, you must use a pair of identical DDR3L modules. |
| Flash Memory |
512MB (Dual boot OS protection) |
| Drive Bay |
4 x 3.5-inch SATA 6Gb/s, 3Gb/s The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/ |
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| M.2 SSD Slot |
Optional via a PCIe adapter |
| SSD Cache Acceleration Support |
|
| Gigabit Ethernet Port (RJ45) |
4 Expandable with an optional PCIe adapter |
| 10 Gigabit Ethernet Port |
1 x 10GBASE-T (10G/5G/2.5G/1G/100M) Pre-installed QXG-10G1T PCIe adapter |
| Jumbo Frame |
|
| PCIe Slot |
1
Slot 1: PCIe Gen 2 x4 Pre-installed QXG-10G1T PCIe adapter |
| USB 2.0 port |
3 |
| USB 3.2 Gen 1 port |
2 |
| USB 3.2 Gen 2 (10Gbps) Port |
Optional via a PCIe expansion adapter |
| Form Factor |
1U Rackmount |
| LED Indicators |
HDD 1-4, Status, USB, LAN |
| Buttons |
Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) |
44 × 439 × 499 mm |
| Weight (Net) |
7.58 kg |
| Weight (Gross) |
9.54 kg |
| Operating temperature |
0 - 40 °C (32°F - 104°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
250W, Input: 110-240 Vac~, 50-60Hz, 5A |
| Power Consumption: HDD Sleep Mode |
34.06 W |
| Power Consumption: Operating Mode, Typical |
50.46 W |
| Sound Level |
36.5 db(A) |
| System Warning |
Buzzer |
| Max. Number of Concurrent Connections (CIFS) |
800 |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications. Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
|
|
|
|
