Analog Input
- Photo-isolation: 3750 Vrms
- Type: mV, V , mA (requires optional external 125 ohm resistor)
- Thermocouple: Type J, K, T, E, R, S, B, N, C, L, M
- Input Channel: 1
- Voltage range: +/-15mV, +/-50mV, +/-100mV,+/- 500mV,
+/-1V,+/- 2.5V
- Current range: +/- 20mA
- Resolution: 16-bit
- Sampling rate: 10 Samples/Second
- Bandwidth: 5.24 Hz
- Input impedance: 20M ohms
- Accuracy: ±0.05%
- Zero Drift: ± 0.5uV/℃
- Span Drift: 25ppm/℃
- CMR @ 50/60 Hz: 150 dB
- NMR @ 50/60 Hz: 100 dB
- Over voltage protection:35V (P-P)
- Isolation: 3000Vrms
|
Thermocouple type : (C)
| Type |
Range (°C) |
| J |
-210 ~ +760 |
| K |
-270 ~ +1372 |
| T |
-270 ~ +400 |
| E |
-270 ~ +1000 |
| R |
0 ~ +1768 |
| S |
0 ~ +1768 |
| B |
0 ~ +1820 |
| N |
-270 ~ 1300 |
| C |
0 ~ 2320 |
| L |
-200 ~ 800 |
| M |
-200 ~ 100 |
|
